medlar 5000*3 pixel camera sorting machine from China manufacturer

medlar 5000*3 pixel camera sorting machine

Price:	33000.0~52000.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Anhui, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HJ-C4R

Production Capacity: 25sets/Month

Delivery Date: 20 days

Color: Blue/Green

Size: 180*142*143cm

Filter: YSC/CKD

Means of Transport: Ocean

Packing: In wooden case

Brand Name: TORCH

Material of frame: Steel or stainless steel

Camera: SONY

Place of origin: Hefei,China

sorting machine
Famous brand
Japan CCD camera chip
YSC/CKD filter
LED light source
Recognition accuracy up to 0.04mm

Medlar High Quality CCD color sorter
Medlar LED light source CCD color sorter
Description:

1.Our control chip is made in the USA.The combination of DSP and FPGA produces powerful computing capabilities.It has extremely fast data collection and can process large amounts of information and perform various operations stimultaneously.Distinguished performance to kinds of colorful products in graininess

2.300mm wide chute which is smoothness, abrasion-resistance, resistance to wear and tear and corrosion-resistance is built with a special anodizing process and was designed to meet specifications required for many applications around the world.

3.CCD Camera:A Japanese high-end 5000*3 pixel CCD chip camera can identify spots as small as 0.04mm.When coupled with intelligent algorithms,the optical design provides a more accurate color selection.

4.Ejectors: Matrix from Italy.The ejectors contain a high-frequency electromagnetic solenoid valve that operate with a 14 billion millisecond precision and a consistency of near-zero error to ensure high accuracy.

5.Adopted with high-brightness,lasting stability and longer life-time LED light which not only help save more power but also reduce cost.

6.Professional researching and developing team have researched a special program which make the machine easily distinguished different color with the program,such as red,blue,green,yellow and so on.the program can ensure the sorter have a distinguished sorting effect.

7.Large LCD touch screen,a friendly user interface, easy to learn and operate.

Competitive Advantage:
1.5000*3 pixel CCD camera and photo processing technology
2. Recognition accuracy up to 0.04mm
3. Passed CE, UL, ETL, ISO9001
4. LED TFT real 10 inch screen
5. Self checking system

6.Matrix ejector make sure the performance of machine more stable.

Specification of Medlar LED light source CCD color sorter:

PARAMETER OF COLOR SORTER

ITEM.NO	HJ-C2R	HJ-C3R	HJ-C4R	HJ-C5R	HJ-C6R
Machine weight(kg)	850	900	950	1050	1150
Channels	126	189	252	315	378
Cameras	4	6	8	10	12
Light source	LED light	LED light	LED light	LED light	LED light
Pixel of camera	5000*3	5000*3	5000*3	5000*3	5000*3
Ejector	Matrix	Matrix	Matrix	Matrix	Matrix
CCD chip	Japan	Japan	Japan	Japan	Japan
The smallest size recognition	0.04mm	0.04mm	0.04mm	0.04mm	0.04mm
Sorting accuracy	>99.95%	>99.95%	>99.95%	>99.95%	>99.95%
Rejection ratio	>10:1	>10:1	>10:1	>10:1	>10:1
Host power	1.0	1.2	1.4	1.6	1.8
Air pressure	≥0.6Mpa	≥0.6Mpa	≥0.6Mpa	≥0.6Mpa	≥0.6Mpa
Air consumption (L/min)	500-1500	600-2000	700-2500	800-3000	850-3500
Radiating mode	Wind cooling	Wind cooling	Wind cooling	Wind cooling	Wind cooling
Power supply (Voltage/HZ)	220V/50HZ	220V/50HZ	220V/50HZ	220V/50HZ	220V/50HZ
Package Material	Wooden case	Wooden case	Wooden case	Wooden case	Wooden case
Warranty	12 months	12 months	12 months	12 months	12 months
