carrot granule sorting machine/carrot

Price: 33000.0~52000.0 USD
Payment Terms: T/T,L/C
Place of Origin: Anhui, China (Mainland)
inquire skype
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: HJ-C4R
Production Capacity: 25sets/Month
Delivery Date: 20 days
color: Blue/Green
Size: 180*142*143cm
Filter: YSC/CKD
Means of Transport: Ocean
Packing: In wooden case
Brand Name: TORCH
material: steel or stainless steel
Camera: Japan
Place of origin: Hefei,China

High working capacity
Intelligent touch screen
Professional Technical support
Competitive price
One year's warranty

Carrot granule color sorter
Carrot granule color sorter
Description
:

1.Our control chip is made in the USA.The combination of DSP and FPGA produces powerful computing capabilities.It has extremely fast data collection and can process large amounts of information and perform various operations stimultaneously.Distinguished performance to kinds of colorful products in graininess

2.300mm wide chute which is smoothness, abrasion-resistance, resistance to wear and tear and corrosion-resistance is built with a special anodizing process and was designed to meet specifications required for many applications around the world.

3.CCD Camera:A Japanese high-end 5000*3 pixel CCD chip camera can identify spots as small as 0.04mm.When coupled with intelligent algorithms,the optical design provides a more accurate color selection.

4.Ejectors: Matrix from Italy.The ejectors contain a high-frequency electromagnetic solenoid valve that operate with a 14 billion millisecond precision and a consistency of near-zero error to ensure high accuracy.

5.Adopted with high-brightness,lasting stability and longer life-time LED light which not only help save more power but also reduce cost.

6.Professional researching and developing team have researched a special program which make the machine easily distinguished different color with the program,such as red,blue,green,yellow and so on.the program can ensure the sorter have a distinguished sorting effect.

7.Large LCD touch screen,a friendly user interface, easy to learn and operate.


Competitive Advantage:
1.5000*3 pixel CCD camera and photo processing technology
2. Recognition accuracy up to 0.04mm
3. Passed CE, UL, ETL, ISO9001
4. LED TFT real 10 inch screen
5. Self checking system

6.Matrix ejector make sure the performance of machine more stable.


Specification of
Carrot granule color sorter:

PARAMETER OF COLOR SORTER

ITEM.NO

HJ-C2R

HJ-C3R

HJ-C4R

HJ-C5R

HJ-C6R

Machine weight(kg)

850

900

950

1050

1150

Channels

126

189

252

315

378

Cameras

4

6

8

10

12

Light source

LED light

LED light

LED light

LED light

LED light

Pixel of camera

5000*3

5000*3

5000*3

5000*3

5000*3

Ejector

Matrix

Matrix

Matrix

Matrix

Matrix

CCD chip

Japan

Japan

Japan

Japan

Japan

The smallest size recognition

0.04mm

0.04mm

0.04mm

0.04mm

0.04mm

Sorting accuracy

>99.95%

>99.95%

>99.95%

>99.95%

>99.95%

Rejection ratio

>10:1

>10:1

>10:1

>10:1

>10:1

Host power

1.0

1.2

1.4

1.6

1.8

Air pressure

≥0.6Mpa

≥0.6Mpa

≥0.6Mpa

≥0.6Mpa

≥0.6Mpa

Air consumption (L/min)

500-1500

600-2000

700-2500

800-3000

850-3500

Radiating mode

Wind cooling

Wind cooling

Wind cooling

Wind cooling

Wind cooling

Power supply (Voltage/HZ)

220V/50HZ

220V/50HZ

220V/50HZ

220V/50HZ

220V/50HZ

Package Material

Wooden case

Wooden case

Wooden case

Wooden case

Wooden case

Warranty

12 months

12 months

12 months

12 months

12 months


Spare parts of Carrot granule color sorter:

Air storage tank
Volume of storage: one cube meter


Carrot granule color sorter

Air compressor
Power:15kw+15kw
Voltage and frequency:380V/50HZ

Carrot granule color sorter

Workshop of Carrot granule color sorter:
Carrot granule color sorter

Flow chart of Carrot granule color sorter:
Carrot granule color sorter

Drawing of HJ-C4R Carrot granule color sorter's feeder hopper and work table:
Carrot granule color sorter
Carrot granule color sorter
