plastic sorting machine/plastic seperator from China manufacturer

plastic sorting machine/plastic seperator

Price:	33000.0~52000.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Anhui, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HJ-C2R

Production Capacity: 25sets/Month

Delivery Date: 15 days

Material of frame: Steel/stainless steel

Camera: SONY

Place of origin: Hefei,China

Means of Transport: Ocean

Packing: In wooden case

Color: Blue/Green

Size: 118*142*140cm

Filter: YSC/CKD

High working capacity
Outstanding performance
Intelligent touch screen
Automatic control
Multi-function,suit for different materials

Plastic flakes 5000*3 pixel CCD color sorter

Plastic flakes 5000*3 pixel CCD color sorter
Description:

1.Our control chip is made in the USA.The combination of DSP and FPGA produces powerful computing capabilities.It has extremely fast data collection and can process large amounts of information and perform various operations stimultaneously.Distinguished performance to kinds of colorful products in graininess

2.300mm wide chute which is smoothness, abrasion-resistance, resistance to wear and tear and corrosion-resistance is built with a special anodizing process and was designed to meet specifications required for many applications around the world.

3.CCD Camera:A Japanese high-end 5000*3 pixel CCD chip camera can identify spots as small as 0.04mm.When coupled with intelligent algorithms,the optical design provides a more accurate color selection.

4.Ejectors: Matrix from Italy.The ejectors contain a high-frequency electromagnetic solenoid valve that operate with a 14 billion millisecond precision and a consistency of near-zero error to ensure high accuracy.

5.Adopted with high-brightness,lasting stability and longer life-time LED light which not only help save more power but also reduce cost.

6.Professional researching and developing team have researched a special program which make the machine easily distinguished different color with the program,such as red,blue,green,yellow and so on.the program can ensure the sorter have a distinguished sorting effect.

7.Large LCD touch screen,a friendly user interface, easy to learn and operate.

Competitive Advantage:
1.5000*3 pixel CCD camera and photo processing technology
2. Recognition accuracy up to 0.04mm
3. Passed CE, UL, ETL, ISO9001
4. LED TFT real 10 inch screen
5. Self checking system

6.Matrix ejector make sure the performance of machine more stable.

Specification of Plastic flakes 5000*3 pixel CCD color sorter:

PARAMETER OF COLOR SORTER

ITEM.NO	HJ-C2R	HJ-C3R	HJ-C4R	HJ-C5R	HJ-C6R
Machine weight(kg)	850	900	950	1050	1150
Channels	126	189	252	315	378
Cameras	4	6	8	10	12
Light source	LED light	LED light	LED light	LED light	LED light
Pixel of camera	5000*3	5000*3	5000*3	5000*3	5000*3
Ejector	Matrix	Matrix	Matrix	Matrix	Matrix
CCD chip	Japan	Japan	Japan	Japan	Japan
The smallest size recognition	0.04mm	0.04mm	0.04mm	0.04mm	0.04mm
Sorting accuracy	>99.95%	>99.95%	>99.95%	>99.95%	>99.95%
Rejection ratio	>10:1	>10:1	>10:1	>10:1	>10:1
Host power	1.0	1.2	1.4	1.6	1.8
Air pressure	≥0.6Mpa	≥0.6Mpa	≥0.6Mpa	≥0.6Mpa	≥0.6Mpa
Air consumption (L/min)	500-1500	600-2000	700-2500	800-3000	850-3500
Radiating mode	Wind cooling	Wind cooling	Wind cooling	Wind cooling	Wind cooling
Power supply (Voltage/HZ)	220V/50HZ	220V/50HZ	220V/50HZ	220V/50HZ	220V/50HZ
Package Material	Wooden case	Wooden case	Wooden case	Wooden case	Wooden case
Warranty	12 months	12 months	12 months	12 months	12 months

Air-supplied system of Plastic flakes 5000*3 pixel CCD color sorter:

Air storage tank
Volume of storage: one cube meter

Air compressor
Power:7.5kw+7.5kw
Voltage and frequency:380V/50HZ

Packing details of Plastic flakes 5000*3 pixel CCD color sorter:
The machine and spare parts would be packed in 4 wooden cases as below:
Case No 1:color soter
Case No 2:air compressor
Case No 3:air storage tank
Case No 4:spare parts

Workshop:

Flow chart of Plastic flakes 5000*3 pixel CCD color sorter:

Drawing of 2R Plastic flakes 5000*3 pixel CCD color sorter's feed hopper and work table:
